Side view toward the rear of a pneumatic overlay trailer: PolyQuip pump cabinet, A side load panel and stainless A side tank on the deck, crew broadcasting aggregate on the bridge deck behind it
Epoxy dispensing and EPC batching equipment

Equipment that mixes epoxy right, and proves it.

PolyQuip designs and builds metered dispense systems for pneumatic overlay and epoxy polymer concrete volumetric and batch plant trucks and trailers. Built for bridge-deck overlay and infrastructure contractors. Every rig records what it put down.

Engineered systems

Pneumatic overlay trailers

100% electric

  • One 60 kW three-phase generator powers the entire trailer.
  • One motor to maintain.
  • Variable-speed electric Roots blower pressurizes and conveys the rock.
  • One operator station runs the entire machine. No running around the trailer to check on motors and equipment.
  • The operator stays at the back of the machine, where the work is getting done.
  • Pressure, temperature and mix ratio are displayed in real time at the operator station.
  • Mix ratio is monitored in real time. The pumps shut down within seconds of a ratio or pressure problem.
  • Epoxy calibration is verified by weight. Meets multiple states' requirements for material calibration.
  • Cold-weather start-up: epoxy recirculates through the system before production, warming the pumps and lines all the way to the back of the trailer.
Request a quote
Engineered systems

Epoxy polymer concrete (EPC): volumetric and batch plant systems

  • One 30 kW three-phase generator powers the entire plant.
  • Calibrated sand, rock and epoxy. Meets requirements for multiple state certifications.
  • Fully adjustable batch sizes, set from the operator station.
  • Mix ratio is displayed in real time at the operator station.
  • The pumps shut down within seconds of a ratio or pressure problem.
  • Job data saved per batch and per job.
  • Cold-weather start-up: epoxy recirculates through the system before production, warming the pumps and lines.
Request a quote
Engineered systems

Customer-owned upgrades and revamps

  • We work with the customer on equipment they already own.
  • The goal is to get that equipment working better for them.
  • We keep as many of the original components as possible.
  • We integrate newer technology into the existing platform.
  • We integrate better controls into the existing platform.
Request a quote
Data

Data collection, GPS and the customer portal

The controls on a PolyQuip rig do more than run the pumps. The PLC writes down what the machine did and where it was when it did it, and the rig sends that home over cellular. The owner sees every pass and every batch without waiting on paperwork from the field.

Sample machine6 AM to 6 AM report day

Loading the sample map… Tap a point to see its row, or a row to find it on the map. Coloured by job; grey is pumps off.

Data collection and GPS

Every row tied to where the rig was

The PLC logs as the rig runs: one row a minute on a pump trailer, a row every 100 feet of travel on an automatic trailer, one line per batch on the batch plant. Each row carries the GPS position, so the record shows where the material went, not only how much.

  • JobJob and batch number, time stamped
  • EpoxyA, B and total gallons, flow, mix ratio
  • MaterialA and B temperature, pump pressure
  • CoverageFeet traveled, feet per minute, sq ft per gallon
  • Batch plantRock and sand per batch
  • LocationGPS position on every row
Ask about data on your rig
Customer portal

Sign in and see your machines

Customers sign in to the PolyQuip portal. Each machine page is a map and a table of the same rows, linked both ways, like the sample above. Pick a day or a range, choose the columns, and download.

  • MapColoured by job, pumps off in grey
  • Range6 AM to 6 AM report day, presets or custom
  • JobsEvery job on one map
  • DownloadsExcel, CSV, Google Earth (KML)
Open the portal demo
Production emails

A daily report to whoever needs it

Each machine can send a production report for the 6 AM to 6 AM day. The customer chooses who gets it, from the office to the field, and which columns it carries. The same map and table as the portal, as attachments.

  • RecipientsUp to 20 addresses, set by the customer
  • ScheduleDaily at 7 AM or weekly on Monday
  • ColumnsThe customer's own portal setup
  • AttachedExcel sheet, map dashboard, Google Earth file
Request a quote

What a batch ticket looks like

Rows from a real epoxy polymer concrete overlay pour, job details removed. One line per batch, written by the plant.

BatchSize (cu ft)Rock (lb)Sand (lb)Epoxy (gal)Resin %Ratio check
221244889618.0011.61%0.00%
231244889617.9911.60%0.00%
241244889617.9911.60%0.00%
251244889617.9811.59%0.00%
261244889617.9911.60%0.00%

When an inspector asks what went down on a pour, the answer is a printout, not a memory.

Replacement parts

Keep the rig running.

Wear parts and replacement components for PolyQuip systems. Tell us the machine and the part, and we will match it to your build. Ordering is by request for now.

Support

24-hour remote support.

We connect to your machine's PLC over cellular and work with your operator on the phone.

How remote support reaches a machine A trailer with a PolyQuip machine on the deck sends a signal to a cell tower, across the network to a second tower, and down to a support desk with two monitors showing the machine's PLC program. Your machine, on the job Cellular network PolyQuip support
Contact

Tell us how we can help.

Send us a message and we will get back to you.
